FEATURES
·3 3/4-digit backlight LCD, with a max. reading of 3999
·Analog bar graph, reading unit indication
·Manual and autoranging mode
·Polarity indication
·Relative mode
·Vehicle’s battery internal resistance test function
·Max./Min. mode
·Data-hold mode
·Overrange indication
·Low battery indication
·Auto power of
SPECIFICATION
Battery Test: 400m/4000mΩ (<36V, 1kHz 50mA)
Dwell Angle: 2-3-4-5-6-8CYL (180°/120°/90°/72°/60°/45°
Tacho: 250~40kRMP, Highest Resolution: 1RMP
Voltage DC: 400m/4/40/400/600V
Voltage AC: 4/40/400/600V
Current DC: 400μ/4000μ/40m/400mA
Current AC: 400μ/4000μ/40m/400mA
Resistance: 400/4k/40k/400k/4M/40MΩ
Frequency: 4k/40k/400kHz
Duty Cycle: 5% to 90%
Temperature: -20 to 1000?C / 0 to 1832?F
Diode Check: approx.3V
Continuity: less than about 30Ω
Power Supply: 9V(6F22) battery×1pc
Dimensions: 165×83×47 mm
Weight: Approx. 300g (Without battery)
Fuse Protection for "A°C°F" Jack Inputs:
500mA, 690V, FAST, Min. Interrupt Rating 20000A
