USB LINK TO PC
Connect the USB data cable supplied with the meter to the terminal on the top of the meter, connect the other end of this cable to the USB port of the computer. The computer will prompt that a new hardware has been found and the USB driver will be installed automatically.
FEATURES
·3 3/4-digit backlight LCD, with a max. reading of 3999
·Manual and autoranging mode
·Dwell Angle, Tacho measurement
·Relative mode
·Automatic power off
·Data-hold mode
·Polarity indication
·Overrange indication
·Low battery indication
·Link to PC
·With the USB2.0 interface, Data Cable and CD
SPECIFICATION
Dwell Angle: 2-3-4-5-6-8CYL (180°/120°/90°/72°/60°/45°
Tacho: 250~40kRMP, Highest Resolution: 1RMP
Voltage DC: 400m/4/40/250V
Voltage AC: 4/40/250V
Current DC: 400μ/4000μ/40m/400m/4/10A
Current AC: 400μ/4000μ/40m/400m/4/10A
Resistance: 400/4k/40k/400k/4M/40MΩ
Frequency: 5/50/500/5k/50k/200kHz
Capacitance: 50n/500n/5μ/50μ/100μ
Duty Cycle: 5%~95%
Temperature: -20~1000?C / -4~1832?F
Diode Check: approx. 1.5V
Continuity: Less than about 50Ω, more than about 120Ω
Power Supply: 9V(6F22) battery×1pc
Dimensions: 165×83×47 mm
Weight: Approx.300g (Without battery)
